Vivotek Indoor Network Horn Speaker - AU-004

Product Information

• Rated Impedance: 8 ohms
• Average Minimum Power: 15W
• Frequency Ranges (±10dB): 500–2000 Hz
• Frequency Ranges (±20dB): 400–12000 Hz
• Maximum Sound Pressure Level: 96 dB
• Microphone: 50Hz–20kHz at 1Pa, 50cm distance, SPL 115dB at 1kHz


Network

• SIP Support: RFC 3261
• Interface: WAN: RJ-45x1, 10/100Mbps Fast Ethernet port
• Supported Protocols:
  SIP, ONVIF, HTTP, IPv4, DHCP, RTSP, RTP, RTCP, TCP, UDP, ARP, FTP, TFTP, NFS, NTP
• Audio Codec:
  OPUS 48 kHz, MP3 44.1 kHz, G.722 ADPCM 16 kHz, G.711 PCMU 8 kHz, G.711 PCMA 8 kHz
• Security:
  Password protection, IP address filtering, Digest authentication, firewall


VSS Integration

• Two-way Communication: Supported
• Automatic Trigger Audio Clips: Supported


General

• Casing: Metal
• Power: PoE (Power over Ethernet, IEEE 802.3af) or DC 12-24V
• Operating Temperature: -35°C ~ 60°C (-31°F ~ 140°F)
• Dimensions: 200 x 90 mm
• Weight: 1 kg
• Certifications: CE, FCC, VCCI, BSMI
