Uniview 32 Channel, 4 SATA Interface Network Video Recorder - NVR504-32B

Uniview 32 Channel, 4 SATA Interface Network Video Recorder - NVR504-32B

$1,109.00 USD
$1,109.00 USD
Sale Sold out
Shipping calculated at checkout.

Get the ultimate surveillance solution with the Uniview 32 Channel Network Video Recorder (NVR504-32B). With 32 channels and 4 SATA interfaces, this NVR offers high-performance recording and storage capabilities for large-scale security systems. Trust in this expertly designed and reliable NVR for all your surveillance needs.

Features

  • Uniview
  • NVR for IP cameras
  • Prime range
  • 32 CH
  • 320 Mbps bandwidth supported
  • Maximum resolution 8 Megapixel
  • 2 x RJ45
  • Compression Ultra265/H.265/H.264
  • VGA and HDMI 4K output
  • Mouse
  • Space for 4 HDD
  • ONVIF Compatible
  • Smart Features
  • Compatible with people counting
  • Supports vehicle detection
  • SIP compatible
  • Supports fire and temperature detection
  • UMD


Specifications

Brand Uniview
Range Prime
IP compatible cameras UNIVIEW, ONVIF
Video outputs 1 HDMI 4K, 1 VGA
Video compression format Ultra H.265 / H.265 / H.264
Network interface 2 RJ-45 10M / 100M / 1000M
Display resolution 3840x2160, 1920x1080, 1600x1200 1280x1024, 1280x720, 1024x768
Total bandwidth 320 Mbps downstream / 160 Mbps upstream
Main Stream recording 8Mpx / 6Mpx 5Mpx 4Mpx / 3Mpx / 1080p 720p / D12CIF / CIF
Smart features by camera 8 channels
VCA detection by camera Intrusion detection, Cross line detection, Entry area, Exit area, Blur detection, Scene change detection, Object left behind, Object removed, Auto tracking, UMD (Ultra Motion Detection)
Recording method Manual, programmed, motion detection
External Backup USB / HDD USB memory
Internal memory 4 SATA HDD 3.5" of up to 8 TB (not included)
Communication 2 x USB 2.0 / 2 x RJ45 (Ethernet)
Bidirectional audio 1 input / 1 RCA output
Alarms 16 Inputs / 4 Outputs
Remote access Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive)
Power 12 V CC/5 A ≤ 20 W (without hard disk)
Dimensions / Weight 440mm × 344mm × 48mm / 3,15 Kg
