Vivotek 2MP Indoor Fixed Dome Network Camera - FD9165-HT-A
Vivotek 2MP Indoor Fixed Dome Network Camera - FD9165-HT-A
Regular price
$788.40 USD
Regular price
Sale price
$788.40 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Product Specification
System Information
| Component | Specification |
|---|---|
| CPU | Multimedia SoC (System-on-Chip) |
| Flash | 256 MB |
| RAM | 1 GB |
Camera Specifications
| Feature | Specification |
|---|---|
| Image Sensor | 1/2" Progressive CMOS |
| Max. Resolution | 1920x1080 (2MP) |
| Lens Type | Motorized, Vari-focal, Remote Focus |
| Focal Length | f = 4 ~ 9 mm (f = 2.8 ~ 11.4 mm, equivalent focal length @ 1/2.8") |
| Aperture | F1.3 ~ 2.2 |
| Iris Type | P-iris |
| Field of View | Horizontal: 120° ~ 46° Vertical: 60° ~ 26° Diagonal: 152° ~ 53° |
| Shutter Time | 1/5 sec. to 1/32,000 sec. |
| WDR Technology | WDR Pro |
| Day/Night | Yes |
| Removable IR Filter | Yes |
| Illuminators | Built-in IR illuminators, effective up to 50m with Smart IR II, IR LED *4 |
| Minimum Illumination | 0.015 lux @ F1.3 (Color) <0.005 lux @ F1.3 (B/W) 0 lux with IR on |
| Pan Range | 350° |
| Tilt Range | 60° |
| Rotation Range | ±175° |
Pan/Tilt/Zoom Functionalities
| Feature | Specification |
|---|---|
| ePTZ | 48x digital zoom (4x on IE plug-in, 12x built-in) |
Storage
| Feature | Specification |
|---|---|
| Recording | MicroSD/SDHC/SDXC card (256GB max), NAS supported |
Built-in Installation Aids
| Feature | Specification |
|---|---|
| Installation | Remote focus, remote zoom, CVBS |
Video Specifications
| Feature | Specification |
|---|---|
| Compression | H.265, H.264, MJPEG |
| Max. Frame Rate | 30 fps @ 1920x1080 (WDR Pro on), 60 fps @ 1920x1080 (WDR Pro off) |
| Max. Streams | 3 simultaneous streams |
| Dynamic Range | 120 dB |
| S/N Ratio | 68dB |
| Image Settings | White balance, defog, 3DNR, anti-overexposure, flip/mirror/rotation |
Audio
| Feature | Specification |
|---|---|
| Audio Capability | Two-way Audio (Full Duplex) |
| Compression | G.711, G.726 |
| Interface | Built-in mic, external mic input, line output |
| Range | Effective up to 5 meters |
Network
| Feature | Specification |
|---|---|
| Users | Live viewing for up to 10 clients |
| Security | HTTPS, IEEE 802.1x, password protection, Trend Micro IoT Security |
| Protocols | 802.1X, DHCP, FTP, IPv4/IPv6, RTSP, TLS 1.2, UPnP |
Interface
| Feature | Specification |
|---|---|
| Ethernet | 10 Base-T/100 Base-TX Ethernet (RJ-45) |
Event Triggers and Actions
| Trigger | Specification |
|---|---|
| Event Triggers | Motion detection, audio detection, tampering, PIR detection |
| Event Actions | Notification via audio, email, SD card, FTP |
General Specifications
| Feature | Specification |
|---|---|
| Power Input | IEEE 802.3af PoE, DC 12V, AC 24V |
| Power Consumption | Max 11 W (PoE), 8 W (DC), 9.5 W (AC) |
| Certifications | CE, FCC, RCM, VCCI, UL, CB, BIS |
| Dimensions | Ø 139 x 103 mm |
| Weight | 538 g |
Operating Conditions
| Feature | Specification |
|---|---|
| Temperature | Starting: 0°C ~ 45°C Working: -10°C ~ 45°C |
| Humidity | 0.9 Relative Humidity |
