Uniview 4-Port PoE Switch - NSW2010-5T-PoE-IN

Uniview 4-Port PoE Switch - NSW2010-5T-PoE-IN

Regular price $119.00 USD
Regular price Sale price $119.00 USD
Sale Sold out
Shipping calculated at checkout.

The Uniview 4-Port PoE Switch - NSW2010-5T-PoE-IN is a powerful networking solution for professionals. With 4 Ports and PoE capabilities, this switch offers high-speed data transfer and power delivery for devices such as IP cameras, VoIP phones, and wireless access points. Increase efficiency and connectivity with Uniview.

Features

  • 5x 10/100Mbps Ethernet Ports
  • 4x 10/100Mbps ports support PoE)
  • All 100mbps ports support PoE
  • PoE Complies with IEEE802.3af/at, up to 30w for single port.
  • Support 250m(928ft) extended PoE transmission when used with UNV IP cameras
  • Easy to use, no need to configure
  • High Quality Metal Housing
  • Lightning Protection 6KV


Specifications

Item Download
Ports 5×10/100Base-TX autosensing Ethernet ports(4 10/100Mbps ports support PoE)
Port attribute 10/100 Mbit/s transfer rate
Half-duplex, full-duplex and auto-negotiation
Auto MDI/MDIX
Standards IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3af
IEEE 802.3at
MAC 1K
Packet Forwarding Rate 0.74Mbps
Switching Capacity 1Gbps
EXTEND Mode Standard: the switch functions as a common un-managed switch and all the ports of the switch can communicate with each other.
Extend Mode: If the extend mode is enabled, the transmission distance of both power and data will extend up to 250m(10Mbps), this function can replace the extender and parts of the Fiber. It will extend the distance of the whole system and save the cost of the project.
Status LEDs Link/Act (steady yellow): link is normal
Link/Act (flashing yellow): data is being forwarded
Link/Act (off): no link

PoE (steady green): the port is powering a powered device properly
PoE (off): the port is not connected to any powered device or is not supplying power

Power (steady green): AC input is normal
Power (off): AC input is abnormal
PoE Port 1 to Port 4 support standard IEEE802.3at/af power( maximum power for each port is 30W),
PoE power type is end-span(12+, 36- and 45+, 78- line pair)
Max PoE capacity: 57.8W
Consumption ≤ 63.7 W
DC Voltage 51 V , 1.25A
Operating Temperature 0°C-40°C (32°F-104°F)
Operating Humidity 10%~90% non-condensing
Storage Temperature -40°C-70°C (-40°F-158°F)
Storage Humidity 5%-90% non-condensing
Dimensions (WxDxH) 100mm*100mm*26mm
Certification FCC, CE, RoHS
