Uniview 4-ch HDMI Output Decoding Card - FB-HD04-B-NB

Uniview 4-ch HDMI Output Decoding Card - FB-HD04-B-NB

Regular price $1,519.00 USD
Regular price Sale price $1,519.00 USD
Sale Sold out
Shipping calculated at checkout.

With the Uniview 4-ch HDMI Output Decoding Card, enjoy crisp and clear video decoding on up to four channels. Connect to your desired display via HDMI output for seamless viewing. Maximize your surveillance system with this advanced card.

Features:

  • Support 4/7-ch HDMI
  • HDMI at up to 4K(3840x2160) resolution
  • All HDMI independent outputs provided
  • Support H.265/H.264 video formats
  • Up to 16 Megapixels resolution recording

Specifications:

Video/Audio Output
HDMI Output HDMI1 & HDMI2:
4K (3840x2160) /60Hz, 4K (3840x2160) /30Hz, 1920x1080 /60Hz, 1920x1080 /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz
HDMI3 & HDMI4:
1920x1080 /60Hz, 1920x1080 /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz

Decoding
Decoding Capability HDMI1 & HDMI2 & HDMI3 & HDMI4:
4 x 16MP@30, 5 x 12MP@30, 8 x 4K@30, 12 x 5MP@30, 16 x 4MP@30, 20 x 3MP@30, 32 x 1080P@30, 54 x 960P@30, 64x 720P@30

Decoding
Multi-window 1/4/5/6/7/8/9/16
Working Environment
Working Temperature -10°C ~ + 55°C (14°F to +131°F)
Working Humidity 10% ~ 90% (non-condensing)
Weight
Weight <1 Kg (2.2 lb)
