American Dynamics IFS08D2OCWITB Illustra Flex 8 Megapixel 4K Outdoor MiniDome Camera, 3.4-9mm Lens, Black
American Dynamics IFS08D2OCWITB Illustra Flex 8 Megapixel 4K Outdoor MiniDome Camera, 3.4-9mm Lens, Black
Couldn't load pickup availability
The IFS08D2OCWITB from American Dynamics is an Illustra Flex 8 Megapixel 4K Outdoor MiniDome Camera with 3.4-9mm Lens, Black. It is designed to offer a high-image quality, feature rich surveillance option for a wide range of applications both indoors and outdoors. The increased amount of pixels per foot in these models improve image detail in wide areas such as loading docks and airport terminals. Also, the outdoor Flex Mini-Dome features built-in IR illuminators to produce clear images at an effective distance in a variety of low light conditions. Installations that strive for a combination of high-resolution and high-performance at a competitive price point, all while simplifying installation and configuration stand to benefit the most from the Flex 4K Mini-Dome.
Features
- IK10-rated vandal resistance for protection against dust and water damage
- IR illumination for clear images in low light conditions on outdoor model
- IntelliZip powerful video compression for bandwidth management
- TrickleStor provides edge-based failover redundancy
- P-iris for image clarity in changing light conditions
- Motion detection for instant intruder alerts
Specifications
| Attribute | Details |
|---|---|
| SKU | IFS08D2OCWITB |
| Features | Audio, Auto Gain Control, Day/Night, Mirror, Motion Detection Tracking, On Screen Display Menu, ONVIF, Privacy Masking, Vandal Resistant, Weather Resistant, Wide Dynamic Range, 4K Resolution |
| Manufacturer | American Dynamics |
| Camera Signal | Network IP |
| Connection Type | Wired |
| Resolution | 8 Megapixel |
| Lens Type | Varifocal |
| Lens Size | 3.4-9mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, M-JPEG, H.265, H.264+ |
| Durability | Vandal Resistant, Weather Resistant |
| Voltage | 24vAC, PoE |
| Dimensions (W x H) | Ø4.8 x 4.2 in (Ø123 x 107 mm) |
| Electronic Shutter | 1/4 - 1/10,000 sec |
| Image Device | Progress Scan RGB CMOS 1/2.5” |
| Minimum Scene Illumination | Color, 1/4s, 30 IRE, AGC: 0.03 Lux, B/W, 1/4s, 30 IRE, AGC: 0.0003 Lux, w/ IR (Outdoor Models): 0.0 Lux |
| Operating Temperature | -58°F to 122°F (-50°C to 50°C) |
| OSD Menu | Multiple languages including English, Spanish, French, German, etc. |
| Power Consumption | 12W |
| Privacy Zone | 9 |
| Protocols | TCP/IP, IPv4, IPv6, TCP, UDP, HTTP, FTP, DHCP, WS-Discovery, DNS, DDNS, RTP, RTCP, RTSP, TLS, Unicast, Multicast, NTP, ICMP, IGMP, SMTP, WS-Security, IEEE 802.1x, PEAP, EAP-TLS, EAPoL, SSH, HTTPS, SOAP, WSAddressing, CIFS, SNMP, UPNP, RTSP, LLDP |
| Weatherproof | IP67 |
| Angle of View | Wide (H/V): 104°/56°, Telephoto (H/V): 42°/24° |
| Motion Detection Tracking | 3 zones supported |
| IR Distance | 30m/98ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Mirror | Yes |
| On Screen Display Menu | Yes |
| Privacy Masking | Yes |
| Wide Dynamic Range | Yes |
| ONVIF | Yes |
- IK10-rated vandal resistance for protection against dust and water damage
- IR illumination for clear images in low light conditions on outdoor model
- IntelliZip powerful video compression for bandwidth management
- TrickleStor provides edge-based failover redundancy
- P-iris for image clarity in changing light conditions
